Introducing Durable Motion Guide Arc Rails from a leading rails manufacturer, crafted for superior precision and smooth performance. These arc rails are designed to meet the demands of applications that require precise angular movements, ensuring high load capacity and long-lasting durability. Manufactured using wear-resistant materials, they provide reliable and efficient guidance for a wide range of industrial machinery. As a trusted rails manufacturer, we focus on delivering high-quality motion guide rails that offer stability, accuracy, and longevity, making them the ideal choice for challenging environments. Upgrade your machinery's motion system with these advanced arc rails. Contact us today for further details and customized solutions!
This precision-engineered product is designed for applications that require accurate angular motion control, offering a gonio sliding range of ± 10°. With a roller diameter of 3 mm and 10 rollers, this product ensures smooth operation and reliable performance, even in demanding environments. Its compact dimensions, including a length of 70 mm, make it suitable for various setups while maintaining robustness, as it weighs just 131 grams per set. Despite its lightweight design, this product can handle significant loads, with an allowable load capacity of 1800 N, a static load of 5600 N, and a dynamic load of 2420 N, offering dependable performance even under heavy usage.
Additionally, the product features a precise roller radius of 110 mm and an angular movement capability of 37°, making it ideal for high-precision positioning. The M3 threaded size allows for easy installation and integration into various systems, ensuring maximum versatility. With an advanced design, including components like the roller radius of 110 mm, a radius of 114 mm (R₁), and 106 mm (R₂), along with a static load capacity of 5600 N, this product stands out for its durability and endurance.
Thanks to its carefully designed structure, including detailed specifications such as the dimensions of AB at 18 mm, B at 8 mm, and C at 8.5 mm, the product is built for precision and long-term use. The dynamic load rating of 2420 N ensures reliable motion control for extended periods, making it an excellent choice for advanced systems requiring consistent accuracy and durability.
